ASTM B209 Aluminum Plate 2024 Aviation Application
2024 T351 Aerospace Grade Aluminium Sheet
Aluminum 2024 is one of the highest strength 2xxx alloys, the copper and magnesium are the main elements in this alloy. The most commonly used temper designs include 2024T3, 2024T351, 2024T4, 2024 T6 and 2024T4. The corrosion resistance of 2xxx series alloys is not as good as most other aluminum alloys, and corrosion may occur under certain conditions. Therefore, these sheet alloys are usually clad with high-purity alloys or 6xxx series magnesium-silicon alloys to provide galvanic protection for the core material, thereby greatly improving corrosion resistance.
2024 aluminium alloy is widely used in the aircraft industry, such as aircraft skin sheet, automotive panels, bulletproof armor, and forged and machined parts.
AL clad 2024 aluminum alloy combines the high strength of Al2024 with the corrosion resistance of a commercial pure cladding. Used in truck wheels, many structural aircraft applications, mechanical gears, screw mechanical products, auto parts, cylinders and pistons, fasteners, mechanical parts, ordnance, entertainment equipment, screws and rivets, etc.
|
Chemical Composition WT(%) |
|||||||||
|
Silicon |
Iron |
Copper |
Magnesium |
Manganese |
Chromium |
Zinc |
Titanium |
Others |
Aluminum |
|
0.5 |
0.5 |
3.8~4.9 |
1.2~1.8 |
0.3~0.9 |
0.1 |
0.25 |
0.15 |
0.15 |
Remaining |
|
Typical Mechanical Properties |
||||
|
Temper |
Thickness (mm) |
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
|
T4 |
0.40~1.50 |
≥425 |
≥275 |
≥12 |
|
T4 |
1.50~6.00 |
≥425 |
≥275 |
≥14 |
|
T351 |
0.40~1.50 |
≥435 |
≥290 |
≥12 |
|
T351 |
1.50~3.00 | ≥435 | ≥290 | ≥14 |
|
T351 |
3.00~6.00 | ≥440 | ≥290 | ≥14 |
|
T351 |
6.00~12.50 | ≥440 | ≥290 | ≥13 |
|
T351 |
12.50~40.00 | ≥430 | ≥290 | ≥11 |
|
T351 |
40.00~80.00 | ≥420 | ≥290 | ≥8 |
|
T351 |
80.00~100.00 | ≥400 | ≥285 | ≥7 |
|
T351 |
100.00~120.00 | ≥380 | ≥270 | ≥5 |
Applications
Fuselage structurals
Truck Wheels
Mechanical Screw
Our Advantage
Inventory and Delivery
We have enough product in stock, we can offer enough material to customers. The lead time can be within 7 days for stock materil.
Quality
All the product are from the biggest manufacturer, we can offer the MTC to you. And we can also offer Third-Party test report.
Custom
We have cutting machine, custom size are available.
