China ACP 5080 Casting Aluminum Sheet Ultra Flatness Manufacturers and Suppliers

ACP 5080 Casting Aluminum Sheet Ultra Flatness

Short Description:

Grade: 5052, 5083, 6061, 6082, etc

Type: Flat Precision Plate

Thickness: 4mm~25mm

Flat Tolerance: ±0.1mm

Surface: PE Film with double sides

Place of Origin: Chinese made or Imported

Certification: Mill Certificate, SGS, ASTM, etc

MOQ: 50KGS or Custom

Package: Standard Sea Worthy Packing

Delivery Time: Express within 3 days

Price: Negotiation

Standard Size: 1250*2500mm 1500*3000mm 1525*3660mm

Send email to us Download as PDF

Product Detail

Product Tags

Cutting data display

Thickness tolerance AA Grade ±0.05mm, A Grade ±0.1mm. Flatness ≤0.3mm/mete. Equipped with several semi-automatic / automatic precision cutting equipment in the workshop. The cutting plate thickness range is 4mm~100mm, the maximum plate size is 2200*6000mm. Cutting deformation are very small, effectively improve the rate of finished products. The plate size can be customized with customer requirements.

Features

Surface Luminosity

Surface with polish above 400 mesh, customer can directly anodize, no need to milling surface, which can save the processing time.

Thickness tolerance

Thickness tolerance can touch 0.0mm or +0.05mm, it can completely replace the imported aluminum plate from German and Japan.

Precision cutting

Better production process, effectively improve the rate of finished products, reduce wasting.

Residual elasticity

Cutting deformation are very small, better than normal T651 material. Due to better heat treatment and anneal process, the internal elasticity is small.

Compared with ordinary materials
	Ordinary aluminum plate	Ultra-flat aluminum plate
Thickness tolerance	For work with strict thickness tolerance, thicker plate are required for complex and time-consuming process before cutting.	Thickness tolerance are very high, no need to cutting separately, and no need to milling the surface, it can drastic reduce the processing cost and time。
Flat accuracy	The thicker plate with low flat accuracy not only increase cutting cost, but also need processing from thicker plate.	With excellent flatness, maximum with 0.05mm/㎡, it can reduce the cutting cost also the processing time and salary.
Residual elasticity	It was easily deformation during processing due to the big residual elasticity, shall add the process of elastic release annealing.	With low deformation after process, no need release internal elastic, leveling and other treatment. It can reduce the cost and improve efficiency.

Applications

ELECTRONIC PRODUCT

It is used in the circuit aluminum substrate panel of electronic products or machinery. The flatness difference of aluminum substrate panel in each step of production process, including raw materials. It is easily to cause inaccurate of stamping dimensions due to the bending of the ordinary aluminum plate during the stamping process, which increases production costs, Ultra-flat plate greatly reduces production costs.

PRECISION INSTRUMENT

Ultra-flatness aluminum plates are widely used in precision instruments, which can be processed into soft pack power battery fixtures, 3C soft pack digital battery fixture forming (assembly) equipment, and related precision battery fixtures, especially in the field of new energy.

MACHINING

The features of the ultra-flatness aluminum plate make more machining companies willing to choose it when processing precision parts, which can well guarantee the size and accuracy of the finished product after processing, and greatly reduce the scrap rate during processing, and improve the qualified rate of finished products.

OTHER APPLICATIONS

Other applications like packaging machinery platform, automated machinery platform, 3D printer, inspection equipment, standard panel, detector, robot arm chassis, etc. Ultra-flat panels can solve the products disqualified problems caused by flatness not touch standard, so they are very popular in the industrial field.
